Menu structure of CI 3000
108
Version 2.09 09. April 2014
S Screen 9-3 Interlock, Superuser and Service Mode
Deactivate/activate lock:
With this input screen the input options lock can be released and setpoint values changed.
The release of the lock is only to be carried out by service personnel!
As a general rule: The lock is reactivated no later than 10 minutes after the last keystroke and the
switching on of the operator terminal.
Case A: Without setpoint interlock - without password request:
Press the ENTER key to toggle between block and unblock.
After entering, exit the operating screen by pressing the ESC button.
INTERLOCK Entry Default
Settings
Possible: √ √ = Cancel block to allow settings to be made
↵ -
Case B: With setpoint interlock - with password request:
With activated setpoint interlock (restricted setpoint changes) a password is necessary. The pass
word (6 to 7 characters) must be requested from the manufacturer in conjunction with the specifica
tion of the CI 3000 serial number (see menu 7-2 or the rating plate). It only authorises access for the
current and following day. Afterwards, a new password must be requested! After entering the pass
word, exit the operating screen by pressing the ESC button.
SETPOINT INTERLOCK
Release √
Password: XXXXXXX
√ = lock released
password entry.
