Alarms and Messages of CI 3000
116
Version 2.09 09. April 2014
No. Messages Cause Correction
Hardware faults
8 RTC Fault xxx
or
RTC Fault Mxx
Real-time clock of component xxx defect. Please contact Service Organization
- Replace device
Check device Mxx
9 SIOX X Fault A SIOX extension module (X =1 ...4) has failed
or a cable (terminals 91 - 95, i.e. patch cable) is
defect.
Please contact Service Organization
- Check cabling
- Check patch cable (broken?)
- Replace device
10 Battery Voltage
or
Battery Fault
Real-time clock and RAM backup battery dead. - Change battery (see chapter 5.11)
Check device Mxx
CAN bus faults
41 CAN Bus Overflow
Communication fault on CAN bus, short circuit
between CAN-H and CAN-L.
Check:
CAN bus wiring
correct cable type
CAN bus lenght (max. 500 m)
CAN-GND must be connected every
where,
termination of CAN bus,
wire color scheme everywhere the
same,
no branch lines
42 CAN Bus MSGLOST
(= Message lost)
43 CAN Bus Fault
44 CAN Bus Failure
45 CAN Address Conflict
or
Bus collision Mxx
Same CAN bus address assigned to two com
ponents.
Two components have the same Modbus ad
dress
Change address of one component
Check device Mxx
Messages
46 Time Error Real-clock time implausible on restart. -
47 Adjust Time Time changed on Store Computer.
Time stamps show times before and after chan
ge
-
48 Adjust Date Date changed on Store Computer.
Time stamps show dates before and after chan
ge
-
50 First Start Store Computer performed first start.
All configuration settings and operating archives
deleted.
-
51 Power Failure Store Computer switched off or performed re
set. Time stamps show times of power off and
on.
-
