Menu structure of CI 3000
79
Version 2.09 09. April 2014
S Screen 6-1-2-a
SIGNAL/ALARM INP Page 2 - Configuration Entry Default
Text Freely editable message text (max. 19 characters) Text, number ----
Module XXXX
Module
1)
to which message/alarm signal is supplied
↑, ↓ ----
Submodul XXXX Submodul
1)
to which message/alarm signal is supplied
ONLY visible when module=DDC1..DDC4 is selected
↑ ↓
Channel k
Channel
1)
to which message/alarm signal is supplied
↑, ↓ (number) ----
Priority p Message/alarm input priority ↑, ↓
(number 0..2)
2
Delay 255m Message/alarm delay in minutes ↑, ↓ (number
0 .. 255)
255
Idle Current J N.C. input (Y) / N.O. input (N) ↑, ↓ (Y/N) J
delete Delete message/alarm input:
Displays prompt: Are your sure? No: ESC Yes: ↵
↵, ESC
1)
Designations of modules/channels supported by the CI 3000 Store Computer for digital inputs:
Int.I Internal input AL1 (terminal A1, A2) or AL2 (terminal B1, B2) of CI 3000 Store Computer.
SIOX1 1st Extension Module, channel 1 to 12
SIOX2 2nd Extension Module, channel 1 to 12
SIOX3 3rd Extension Module, channel 1 to 12
SIOX4 4th Extension Module, channel 1 to 12
DDC1 1st BCS DDC module 1
DDC 2 2nd BCS DDC module 2
DDC 3 3rd BCS DDC module 3
DDC 4 4th BCS DDC module 4
Note: (BCS = building control system / DDC = digital direct control)
Only SIOX modules and DDCs that have been appropriately configured in Screen 6-1 are shown for
selection!
S Screen 6-1-3 Special Inputs
Special inputs can be selected from this list by the number 1 to 5.
SPECIAL INPUTS
1 Store closed Store closed (shunt lock) submenu
2 Emerg. Generator Emergency Power submenu
3 Sprinkler Alarm Sprinkler Alarm submenu
4 Store lighting Store lighting submenu
5 Setpoint toggle Setpoint toggle submenu
