Menu structure of CI 3000
80
Version 2.09 09. April 2014
S Screen 6-1-3-1 to 6-1-3-5
The special inputs
- Store closed
- Emergency Generator
- Sprinkler alarm
- Store lighting and
- Toggle Setpoint
can be configured
As the configuration for all the special inputs is identical, the
instructions are provided using the example of the ”Store closed”.
STORE CLOSED Entry Default
.Module XXXX
Module
1)
to which input is connected
↑, ↓ ----
Submodul XXXX Submodul
1)
to which message/alarm signal is supplied
ONLY visible when module=DDC1..DDC4 is selected
↑ ↓
.Channel k
Channel
1)
to which input is connected
↑, ↓ (number) ----
Priority p Input priority ↑, ↓
(number 0..2)
----
Delay 0s Input delay in seconds ↑, ↓ (number)
1 .. 255)
0
Idle Current J N.C. input (Y) / N.O. input (N) ↑, ↓ (Y/N) N
delete Delete message/alarm input:
Displays prompt: Are your sure? No: ESC Yes: ↵
↵, ESC
For each module1) input and associated channel (if appropriate, submodule), the respective message priority
and delay time can be specified. Each channel can be allocated several special inputs!
If activated, the input can be deactivated under the DELETE menu item (parameters are reset to default set
ting). If the input has generated an alarm at the time, the alarm will be reported as sent.
1)
Designations of modules/channels supported by the CI 3000 Store Computer for the digital input:
SIOX1 1st Extension Module, channel 1 to 12
SIOX2 2nd Extension Module, channel 1 to 12
SIOX3 3rd Extension Module, channel 1 to 12
SIOX4 4th Extension Module, channel 1 to 12
DDC 1 1st BCS DDC module 1
DDC 2 2nd BCS DDC module 2
DDC 3 3rd BCS DDC module 3
DDC 4 4th BCS DDC module 4
Note: (BCS = building control system / DDC = digital direct control)
Only SIOX modules and DDCs that have been appropriately configured in Screen 6-1 are shown for
selection!
