Menu structure of CI 3000
85
Version 2.09 09. April 2014
S Screen 6-1-5 EU Archive
This screen is used to select the refrigeration points (UA 300 Series) that are to be archived in accordance with
the EU Directive. Use the up and down cursor keys (↑) (↓) to select the refrigeration points and press the EN
TER key to toggle between active (Y) and not active (N). The remaining memory available for further EU ar
chives is shown for orientation.
EU ARCHIVE Nd.nnn Heading with Node No. of component (0 to 99) Entry Default
Node Name Name of refrigeration point xxxxx xxxxx
Item ID XXXXX Item ID of refrigeration point xxxxx xxxxx
free:xx aktiv:J/N Free:= Free archive memory space (number of archives)
Active = EU archiving active for this refrigeration point?
xxxxx xxxxx
When EU archiving is activated for a refrigeration point, the archive will be created in memory at the
latest after 15 minutes when the first measurement is received. An archive that has been created
cannot be deleted manually. If EU archiving is deactivated for a refrigeration point in this screen, the
archive will be preserved for the time being and will be deleted automatically after a year.
S Screen 6-1-6 Energy Managmt. (Energy management)
ENERGIEMANAGEMENT
1 Meas. Points Measuring Locations submenu
2 Summing Unit Totalizer submenu
3 Load Rejection Load Shedding Manager (LSM) submenu
S Maske 6-1-6-1 Measuring points
MEASURING POINTs
1 Parameterisation Configuration of the measuring points submenu
2 Search M-bus Search M-bus submenu
S Maske 6-1-6-1-1 Parameterisation (of measuring points)
Use the up and down cursor keys (↑) (↓) to scroll through the separate measuring locations. Press ENTER to
configure the measuring location.
Page 1 Select measuring location
MEASURING POINT
Name of measuring location Name of measuring location/ Select
Item ID XXXXX Item ID of measuring location ID
To Next Page
