Menu structure of CI 3000
92
Version 2.09 09. April 2014
S Screen 6-1-6-3-2-a Priority
PRIORITY Entry Default
1 √
2
...
20
Assign priority (1 to 20) to load shedding stage:
Prio 1: First load shed
....
Prio 20: Last load shed
↑, ↓,↵, ESC √
S Screen 6-1-7 Timer
Each timer channel works as an independent week timer with up to 7 control times and can be assigned to a
switching output and/or a pulse output. The output is active when the current time is within one of the 7 config
ured control times.
Page 1: Select timer channel
TIMER hh:mm Heading and current time Entry
Text Name of timer channel ↑, ↓
SK: * SIOX1/1
WK: * SIOX1/2
Name of switching contact channel (SC, if configured)
Name of pulse contact channel (PC, if configured
Currently active output is indicated by *
Only SIOX Extension Modules and DDCs that have been appropriately configured in Screen 6-1are
shown for selection!
Page 2: Configure timer channel
TIMER Entry Default
Name of timer channel Enter freely editable name (max. 19 characters) ↑, ↓, Text ----
Make Contact
.Module SIOXn
.Submodul
.Channel 1
Configure switching contact,
Extension Module (SIOX n=1 to 4) or
(ONLY visible when module=DDC1..DDC4 is selected) and
Channel of switching contact
↑, ↓ ----
Wiping Contct
.Module SIOXn
.Channel 1
Configure pulse contact,
Extension Module (SIOX n=1 to 4) and
channel of pulse contact (pulse duration 5 sec)
↑, ↓
number
----
Mo-Fr 08:00 20:00
Sa 14:00 Mo 08:00
----- ----- -----
...
----- ----- -----
Enter max. 7 control times:
Start time (day hr:min) End time (day hr:min)
OR
Start time (day combination hr:min) End time (hr:min)
↑, ↓
(Mo-Su,Mo-Fr
Mo-Sa,Sa-Su,
------, Mo, Th,
We, Th, Fr,
Sa, Su)
----
delete Delete timer channel:
Displays prompt: Are you sure? No: ESC Yes: ↵
↵, ESC
