Menu structure of CI 3000
91
Version 2.09 09. April 2014
S Screen 6-1-6-3-2 LRM Levels
Use the up and down cursor keys (↑) (↓) to scroll through the separate load shedding stages. Press ENTER to
configure the load shedding stage selected.
Page 1 - Configure load shedding stage
LOAD REJECTION Entry
Level 1 Name of load shedding stage / Select
↑→↵
Name output Name output (e.g. Ventilation Stage 1)
SIOXn/k Extension Module (SIOX n=1 to 4) / c = channel
Page 2 - Configure load shedding stage
Press the ENTER key to configure the load shedding stage.
LOAD REJECTION Entry Default
Name of load shedding stage Name and select load shedding stage (max. 19 characters)
- A name should always be entered for the load shed
ding stage!
↑, ↓, number -
Priority x→ Alarm priority Continue to Screen 6-1-6-3-2
Power XX.XkW Load shed in kW ↑, ↓, number -
min.run.time XXXm Minimum run time (0 to 1440 min.) -
min.duration Minimum allowed duration (0 to 1440 min.) -
max.duration Maximum allowed duration (0 to 1440 min.) -
RejectOutput
.Module SIOXn
.Channel k
Configure load shed output,
Extension Module (SIOX n=1 to 4) and
channel to which load shed output is transmitted
---
Operation input
.Module SIOXn
.Channel k
Configure operating input,
Extension Module (SIOX n=1 to 4) and
channel to which operating input is transmitted
---
Demand input
.Module SIOXn
.Channel k
Configure demand input,
Extension Module (SIOX n=1 to 4) and
channel to which load demand input is transmitted
---
delete Delete load stage:
Displays prompt: Are you sure? No: ESC Yes: ↵
↵, ESC 1
