Menu structure of CI 3000
90
Version 2.09 09. April 2014
S Screen 6-1-6-2-a Measuring Locations
MEASURING POINTS
Name of measuring location Select measuring location associated with totalizer by ENTER () key
Only measuring locations that have been appropriately configured in Screen 6-1-6-1 as a measuring
location (ideally with a measuring location name) are shown for selection!
S Screen 6-1-6-3 Load Rejection
From this list, select the Configuration and Stages submenus for the Load Rejection Manager (LRM) by number
1 or 2.
LOAD REJECTION
1 LRM Configuration LSM Configuration submenu
2 LRM Levels LSM Stages submenu
S Screen 6-1-6-3-1 LRM Configuration
LRM CONFIGURATION Entry Default
Max. Load NT XXXXkW Max. OPT power demand (OPT = off-peak tariff) , , number
1..6000
-
Max. Load HT XXXXkW Max. PT power demand (PT = peak tariff)
Meas. Points Select associate measuring locations 6-1-6-3-1-a Continue to
Screen 6-1-6-3-1-a
Sync Input
.Module SIOXn
.Channel k
Configure sync input,
Extension Module (SIOX n=1 to 4) and
channel to which synchronizing signal for LSM is transmit
ted
, , number ---
Tarifff Input
.Module SIOXn
.Channel k
Configure tariff input,
Extension Module (SIOX n=1 to 4) and
channel to which tariff signal for LSM is transmitted
, , number ---
S Screen 6-1-6-3-1-a Measuring Locations
MEAS. POINTS Entry Default
Name of measuring location Select measuring location associated with LSM by ENTER
() key
, ,, ESC -
Only measuring locations that have been appropriately configured in Screen 6-1-6-1 as a measuring
location (ideally with a measuring location name) are shown for selection!
