Edit Menu WinAQMS Mini DAS User manual 1.0
22
Table 2 Suggested Communication Settings for analysers.
Manufacturer
Model
Baud Rate
Data Bits
Parity
Stop Bits
API (Teledyne)
AMX Series
9600
8
None
1
Dani
TNMH 462
9600
8
None
1
Ecotech
EC 98XX, Serinus
and Aurora series
38400
8
None
1
Termination Panel,
GasCal 1000 (Gas
Calibrator)
4800
8
None
1
Environnement
SA
AC31M, AF21M,
CO11M, O341M
9600
8
None
1
Gill
WindObserverII
(Wind)
9600
8
None
1
ICP DAS
I-7024
9600
8
None
1
Met One
E-BAM
BAM 1020
9600
9600
8
8
None
None
1
1
Monitor Labs
ML 98XX Series
9600
8
None
1
Opsis
AR600, AR650,
LD500
9600
8
None
1
Rupprecht and
Pertashnick
Teom 1400a
9600
8
None
1
Teledyne
M700
9600
8
None
1
Thermo
Environmental
42C, 43C, 48C,
49C and others
9600
8
None
1
Vaisala
PTB220, WS425
9600
8
None
1
Verewa
F-701
1200
8
None
1
Wherever possible WinAQMS Mini DAS handles the special communication
requirements of analysers in software. For example the TEOM 1400a Particulate
Monitor normally requires a special cable but this is handled in software with special
communication settings so that a standard serial cable can be used.
Note: The Monitor Labs 98XX Series of analysers have a
default baud rate setting of 2400 baud. If you set
WinAQMS Mini DAS to communicate with a Monitor Labs
98XX analyser at 9600 baud then you must ensure that the
Multidrop baud in the Interface menu of the analyser is set
to 9600 baud.
