Appendix WinAQMS Mini DAS User manual 1.0

Analogue input 13

Analogue input 14

Analogue input 15

50 PIN IO bits 0-7

BIT 7: Span Out of Range

BIT 6: Span On

BIT 5: Copper Fail

BIT 4: Zero On

BIT 3: Lamp Fail

BIT 2: Out Of Service

BIT 1: Flow Fail

BIT 0: Span Cycle

50 PIN IO bits 8-15

BIT 7: Pump On

BIT 6: Range 1

BIT 5: Startup

BIT 4: Heater Fail

BIT 3: Range 0

BIT 2: IZS On

BIT 1: Spare 1

BIT 0: ZeroCycle

50 PIN IO bits 16-23

BIT 7: Power On

BIT 6: Sys Fail

BIT 5: High Voltage Fail

BIT 4: Power Supply Fail

BIT 3: Electric Test

BIT 2: Optical Test

BIT 1: Range 2

BIT 0: PPm / Metric

50 PIN IO bits 24-31

Really User ID

50 PIN IO bits 32-39

BIT 7: P4

BIT 6: P3

BIT 5: P2

BIT 4: P1

BIT 3: Spare Driver 1

BIT 2:

BIT 1:

BIT 0: Reference Fail

50 PIN IO bits 40-47

BIT 7:

BIT 6:

BIT 5:

BIT 4:

BIT 3:

BIT 2:

BIT 1: P6

BIT 0: P5

50 PIN IO bits 48-55

BIT 7: Status 2 LED

BIT 6: Status 1 LED

BIT 5: Sys Fail LED

BIT 4: HeartBeat LED

BIT 3:

BIT 2:
