Appendix WinAQMS Mini DAS User manual 1.0
78
3 = SPAN
86
Primary Raw Concentration
(before 984X background and gain)
87
Secondary Raw Concentration
(before 984X background and gain)
88
984X Background Concentration
(before gain)
89
Calibration Pressure
90
Converter Efficiency
91
Multidrop Baud Rate
92
Analog Range Gas 1
93
Analog Range Gas 2
94
Analog Range Gas 3
95
Output Type Gas 1
0=Voltage
1=Current
96
Output Type Gas 2
0=Voltage
1=Current
97
Output Type Gas 3
0=Voltage
1=Current
98
Voltage Offset /Current Range Gas1
0=0% or 0-20mA
1=5% or 2-20mA
2=10% or 4-20mA
99
Voltage Offset /Current Range Gas2
0=0% or 0-20mA
1=5% or 2-20mA
2=10% or 4-20mA
100
Voltage Offset /Current Range Gas3
0=0% or 0-20mA
1=5% or 2-20mA
2=10% or 4-20mA
101
Full Scale Gas 1
102
Full Scale Gas 2
103
Full Scale Gas 3
104
Zero Adjust Gas 1
105
Zero Adjust Gas 2
106
Zero Adjust Gas 3
107
Negative 10V Supply
108
50 Pin IO ANIN1
20mV resolution analog input (0-5V)
109
50 Pin IO ANIN2
20mV resolution analog input (0-5V)
110
Instrument State
111
CO Linearisation Factor A
112
CO Linearisation Factor B
113
CO Linearisation Factor C
114
CO Linearisation Factor D
115
CO Linearisation Factor E
116
Instrument Units
0= PPM
1=PPB
2=PPT
3=mG/M
³
4=µG/M
³
5=nG/M
³
117
Background Measure Time
In seconds
118
Sample Fill Time
In seconds
119
Sample Measure Time
In seconds
