Patient Monitor User Manual Calculation and Titration Table
- 117 -
 Dose Type
The data in the titration table will vary with the changes above. And the user can perform the
following:
 Select and to observe more data.
 Record the data displayed in the current window by selecting Record.
19.2 Hemodynamic Calculation
19.2.1 Calculation Procedure
1. The hemodynamic calculation interface is displayed by selecting Menu > Common
Function > Calculation > Hemodynamics.
2. Manually enter the values required on this interface. You can also directly obtain the values
of HR, C.O., PA MAP, CVP, and PAWP if they are available from the monitor by selecting
Get Info.
3. Select Calculate to output parameter value.
19.2.2 Input Parameters
Items
English Full Name/Description
PAWP
Pulmonary artery wedge pressure
CVP
Central venous pressure
C.O.
Cardiac output
HR
Heart rate
EDV
End-diastolic volume
AP MAP
Mean Artery Pressure
PA MAP
Pulmonary artery mean pressure
Height
/
Weight
/
19.2.3 Output Parameters
Items
English Full Name/Description
CI
Cardiac index
BSA
Body surface area
SV
Stroke volume
SVI
Stroke volume index
SVR
Systemic vascular resistance
