Patient Monitor User Manual Product Specification
- 153 -
A Product Specification
NOTE:
The performance of the equipment with ☆ mark is determined to be essential
performance.
A.1 Classification
Anti-electroshock type
Class I equipment and internal powered equipment
Anti-electroshock degree
CF
Ingress Protection
IPX1
Disinfection/sterilization method
Refer to Chapter Care and Cleaning for details.
Working system
Continuous operation equipment
Compliant with Standards
IEC 60601-1: 2005+A1 :2012; IEC 60601-1-2: 2014;
EN 60601-1: 2006+A1 :2013; EN 60601-1-2: 2015;
IEC 60601-2-49: 2011
A.2 Physical Specifications
A.2.1 Size and Weight
Product
Size
Weight
X8
236±2 mm (W)×236±2 mm (H)×147±2 mm (D)
< 2.4 kg
Standard
configurations,
no battery or
accessories
X10
261±2 mm (W)×246±2mm (H)×146±2 mm (D)
< 2.8 kg
X12
306±2 mm (W)×309±2 mm (H)×151±2 mm (D)
< 3.5 kg
A.2.2 Function Configuration
Product
Standard Configuration
Optional Configuration
X8
ECG (3 electrodes), ECG (5 electrodes), RESP,
TEMP (T1), SpO
2
, NIBP
ECG (6 electrodes),
ECG (10 electrodes),
CO
2
, Wi-Fi
X10
ECG (3 electrodes), ECG (5 electrodes), RESP,
TEMP (T1, T2), SpO
2
, NIBP
ECG (6 electrodes),
ECG (10 electrodes),
IBP, CO
2
, Wi-Fi
X12
ECG (3 electrodes), ECG (5 electrodes), RESP,
TEMP (T1, T2), SpO
2
, NIBP
ECG (6 electrodes),
ECG (10 electrodes),
IBP, CO
2
, C.O., Wi-Fi
