Patient Monitor User Manual Product Specification
- 164 -
Sensor
Red Light
(6603) nm
Infrared Light
(90510) nm
Emitted Light Energy
< 15 mW
PI
Measuring Range
0-10, invalid PI value is 0.
Resolution
1
NOTE:
The information about wavelength range can be especially useful to clinicians (for
instance, when photodynamic therapy is performed).
A.8 TEMP
Complies with ISO 80601-2-56: 2009.
Technique
Thermal resistance
Position
Skin, oral cavity, rectum
Measure Parameter
T1, T2, TD(the absolute value of T2 minus T1)
Channel
X8:1
X10/X12:2
Sensor Type
YSI-10K and YSI-2.252K
Unit
C, F
Measuring Range
0 C to 50 C(32 ºF to 122 ºF)
Resolution
0.1 C (0.1 ºF)
☆Accuracy
1
0.3 C
Refresh Time
Every 1 s to 2 s
Temperature Calibration
At an interval of 5 to 10 minutes
Measuring Mode
Direct Mode
Transient Response Time
≤ 30 s
Note 1: The accuracy consists of two parts, as following:
 Accuracy (not including sensor): ± 0.1 C
 Sensor accuracy: ≤ ±0.2 C
