Patient Monitor User Manual Monitoring ECG
- 69 -
8.6.7 ECG Waveform Settings
To change this speed, select ECG Waveform Setup > Sweep, then select an appropriate setting
from the pop-up list. The bigger the value is, the wider the waveform is.
Select ECG Waveform Setup > Cascade: Turn on or off ECG cascade. Cascade means the ECG
waveforms displayed on the screen all occupy the area of two waveforms. This function is valid
only when Screen Layout is set to Normal.
8.7 12-Lead ECG Monitoring
In 12-lead display mode, 12 ECG waveforms and one rhythm lead waveform will be shown at the
waveform area on the screen. The rhythm lead is for ECG calculation before entering 12-lead
display mode. Also, in this mode, the filter mode is set to Diagnosis and cannot be changed.
NOTE:
1 The 12-lead analysis results are for reference only and the clinical significance must
be determined by the physician.
2 If the ECG signal is too weak, the 12-lead analysis results might be affected.
3 Regarding to the standard’s instruction for ECG measurement and analysis of the
monitor, please refer to Smart ECG Measurement and Interpretation Programs User
Manual_EDAN2.
4 For 12-lead analysis, the gain selection contains: 1.25 mm/mV (×0.125), 2.5 mm/mV
(×0.25), 5 mm/mV (×0.5), 10 mm/mV (×1), AUTO gain.
8.7.1 Activating 6/10 Electrodes Monitoring
Select Menu > Maintenance > User Maintain > Other Setups > Activate 6/10 Electrodes in
order to get the SN number which is supposed to be supplied to EDAN for a corresponding
password. Enter the password on the above-mentioned interface and restart the monitor, and the
6/10 Electrodes monitoring function will be activated.
NOTE:
If the 6/10 Electrodes monitoring fails to be activated, users can reenter the password
and try to activate this function again.
8.7.2 Analysis Function
If your monitor is configured with the 12-lead ECG monitoring function, the monitor can perform
automatic analysis function. To perform 12-lead analysis:
1. In the ECG Setup menu, set Electrode Type to 10 Electrodes and set Screen Layout to 12
Leads.
2. Select the shortcut key on the screen directly.
3. The analysis results will be provided in the Diagnosis Review window after approximately
10 seconds.
