Patient Monitor User Manual Monitoring ECG
- 67 -
will automatically switch to PR as the beat source if:
 a valid ECG lead can no longer be measured and
 a PR source is switched on and available.
If an ECG lead becomes available again, the monitor automatically uses HR as beat source and
the monitor gives a “Di” tone with a blinking heart displaying in the HR parameter box
when one heartbeat is detected. While a pulse is detected, the monitor gives a “Da” tone.
8.6.3 Smart Lead Off
When Electrode Type is 5 Electrodes, 6 Electrodes or 10 Electrodes and Smart LeadOff is set
to On, if the selected ECG waveform cannot be measured because of lead-off or other reasons, it
will automatically switch to another available lead channel via which a waveform can be
measured. And the lead name above the display ECG waveform also automatically turns into the
current one.
To change the smart lead off setting, select ECG Setup > Smart LeadOff, and select the desired
setting.
8.6.4 ECG Screen Layout
It varies with Electrode Type. When Electrode Type is set to 3 Electrodes, Screen Layout can
be set to Normal, and it can display one ECG waveform on the main screen.
When Electrode Type is set to 5 Electrodes or 6 Electrodes, Screen Layout can be set to
Normal, Full-Scr and Half-Scr. Select Normal to display two ECG waveforms on the main
screen; select Full-Scr to display seven ECG waveforms which occupy the area of seven
waveforms on the main screen; Select Half-Scr to display seven ECG waveforms on the screen,
occupying the area of four waveforms.
When Electrode Type is set to 10 Electrodes, Screen Layout can be set to Normal and 12
Leads. Select Normal to display two ECG waveforms on the main screen; select 12 Leads to
display 13 ECG waveforms.
When Electrode Type is set to AUTO, the monitor can automatically identify the electrode type
according to the actual connection condition of the electrodes, and provide as much lead data as
possible when the condition of the lead signal is satisfied.
NOTE:
1 If 3 Electrodes is selected in the ECG Setup menu, only Normal can be selected for
Screen Layout in the sub-menu.
2 In 10 Electrodes display interface, the filter can only be set to Diagnosis.
3 If 6 Electrodes is selected in the ECG Setup menu, Va and Vb can be respectively
set to either Lead V1 ~ V6, but cannot be set to the same lead, Va is Lead V2 by
default, Vb is Lead V5 by default.
4 If AUTO is selected in the ECG Setup menu, when the electrodes connected to
patient is reduced from 10 electrodes to 3/5/6 electrodes, user can click Update
