EDAN X8 - VGA Interface (Optional); Wired Network Interface

Patient Monitor User Manual Product Specification
- 171 -
A.13.5 VGA Interface (Optional)
Number of VGA Interface
1
Horizontal Refreshing Rate
(30-94) KHZ
Video Signal
0.7 Vpp @ 75 Ohm, HSYNC/VSYNC signal TTL
Interface Type
DB-15 female receptacle
A.13.6 Wired Network Interface
Specification
100-Base TX (IEEE802.3)
Interface Type
Standard RJ-45 network interface
