Patient Monitor User Manual Product Specification
- 162 -
Measuring Sensitivity
Within the baseline impedance range: 0.3 Ω
Waveform Bandwidth
0.2 Hz to 2.5 Hz (-3 dB)
Respiration Excitation
Waveform
Sinusoid, 45.6 kHz(

10%), < 350 μA
☆RR Measuring Range
☆Adult
0 rpm to120 rpm
☆Neo/Ped
0 rpm to150 rpm
Resolution
1 rpm
☆Accuracy
☆Adult
6 rpm to 120 rpm: 2 rpm
0 rpm to 5 rpm: not specified
☆Neo/Ped
6 rpm to 150 rpm: 2 rpm
0 rpm to 5 rpm: not specified
☆Gain Selection
0.25, 0.5, 1, 2, 3, 4, 5
☆Sweep
6.25 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s
☆Apnea Alarm Time Setup
10 s, 15 s, 20 s, 25 s, 30 s, 35 s, 40 s; default value is 20 s.
A.6 NIBP
Complies with IEC 80601-2-30: 2009+A1: 2013
Technique
Oscillometry
Mode
Manual, Auto, Continuous
Measuring Interval in AUTO
Mode (unit: minutes)
1/2/3/4/5/10/15/30/60/90/120/180/240/360/480
Continuous
5 min, interval is 5 s
Measuring Type
SYS, DIA, MAP, PR
☆Measuring Range
☆Adult Mode
SYS: 25 mmHg to 290 mmHg
DIA: 10 mmHg to 250 mmHg
MAP: 15 mmHg to 260 mmHg
☆Pediatric Mode
SYS: 25 mmHg to 240 mmHg
DIA: 10 mmHg to 200 mmHg
MAP: 15 mmHg to 215 mmHg
