Patient Monitor User Manual Other Functions
- 129 -
Chapter 22 Other Functions
22.1 Nurse Call
The monitor provides dedicated nurse call port which is connected to nurse call system through
the nurse call cable to perform the nurse call function. You should activate the function following
the steps below:
1. Select Menu > Maintenance > User Maintain, and input the password ABC;
2. Select Other Setups > Aux Output;
3. Choose On in the Nurse Call list.
22.2 Analog Output and Defibrillator Synchronization
The monitor provides analog output signals to accessory equipment. Also, if a defibrillator is
connected to the monitor, a defibrillator synchronization pulse can be output. You should activate
the function following the steps below:
1. Select Menu > Maintenance > User Maintain, and input the password ABC;
2. Select Other Setups > Aux Output;
3. Choose Analog Output or Defibrillation in the Aux Output list.
22.3 Wi-Fi
Wi-Fi modules are optional to be configured in the monitors. And you should configure the
settings on the monitor following the steps below before connecting the monitor to a wireless
network:
1. Select Menu > Maintenance > User Maintain, and input the password ABC.
2. In the User Maintain menu, select Network Maintain.
3. In the Network Maintain menu, select Wi-Fi from the Network Type list. And click
Config to open the Wi-Fi Setup window. The available networks will be listed in this
window.
4. Choose a network from the window. You will be prompted to enter the password of that
network if a password is required.
If the monitor is successfully connected to the selected network, it will be indicated by the
message Connected, and the local IP address of the monitor will be displayed in the Wi-Fi Setup
window. Also, a symbol indicating the networking state will be displayed on the lower portion of
the main screen. The meanings of the networking state symbols are explained below:
Wi-Fi signal intensity: Level 4
Wi-Fi signal intensity: Level 3
Wi-Fi signal intensity: Level 2
Wi-Fi signal intensity: Level 1
