Patient Monitor User Manual Alarm Information
- 36 -
Message
Cause
Alarm Level
C.O.
TB High
TB measuring value is above upper alarm.
User-selectable
TB Low
TB measuring value is below lower alarm.
User-selectable
5.2 Technical Alarm Information
NOTE:
The ECG alarm information listed in the below table describes the electrode names in
America. For the corresponding electrode names in Europe, please refer to the section
Installing Electrodes.
Message
Cause
Alarm Level
Action Taken
ECG
ECG Lead Off
1) The drive electrode or
more than one ECG limb
electrode falls off the skin;
2) ECG cables fall off the
monitor.
Low
Make sure that all
electrodes, leads and
patient cables are
properly connected.
ECG LL Lead Off
ECG electrode LL falls off
the skin or the ECG cable LL
falls off the monitor.
Low
ECG LA Lead Off
ECG electrode LA falls off
the skin or the ECG cable LA
falls off the monitor.
Low
ECG RA Lead Off
ECG electrode RA falls off
the skin or the ECG cable RA
falls off the monitor.
Low
ECG RL Lead Off
1) When electrode type is
AUTO, ECG electrode RL
falls off the skin, 5/6/10
electrodes switches to 3
electrodes;
2) When electrode type is
AUTO, the ECG cable RA
falls off the monitor, 5/6/10
electrodes switches to 3
electrodes.
Low
ECG V Lead Off
ECG electrode V falls off the
skin or the ECG cable V falls
off the monitor.
Low
