EDAN X8 - Ibp

Patient Monitor User Manual Product Specification
- 165 -
A.9 PR
Measuring range
Accuracy
Resolution
PR (SpO
2
)
25 bpm to 300 bpm
 2 bpm
1 bpm
PR (NIBP)
40 bpm to 240 bpm
± 3 bpm or 3.5%, whichever is greater
1 bpm
PR (IBP)
20 bpm to 300 bpm
30 bpm to 300 bpm:  2 bpm or  2%,
whichever is greater;
20 bpm to 29 bpm: undefined
1 bpm
A.10 IBP
Complies with IEC 60601-2-34: 2011.
Technique
Direct invasive measurement
Channel
2 channels
IBP
Measure
☆Measuring
Range
Art
(0 to +300) mmHg
PA
(-6 to +120) mmHg
CVP/RAP/LAP/ICP
(-10 to +40) mmHg
P1/P2
(-50 to +300) mmHg
Resolution
1 mmHg
☆Accuracy (not including sensor)
 2 % or 1 mmHg, whichever is greater
ICP:
0 mmHg to 40 mmHg:  2 % or 1
mmHg, whichever is greater;
-10 mmHg to -1 mmHg: undefined
Pressure Unit
kPa, mmHg, cmH
2
O
Pressure sensor
Sensitivity
5 μV/V/mmHg
Impedance Range
300 Ω to 3000 Ω
Filter
DC~ 12.5 Hz; DC~ 40 Hz
Zero
Range:  200 mmHg
Pressure Calibration
Range
IBP (excluding ICP)
80 mmHg to 300 mmHg
ICP
10 mmHg to 40 mmHg
Volume Displacement
7.4 x 10
4
mm
3
/ 100 mmHg
