Patient Monitor User Manual Basic Operation
- 23 -
3.5.3 Adjusting Beat Volume
Beat volume is from HR or PR, depending on your setting of the beat source. To change the beat
volume:
1. Select the shortcut key on the screen directly, or
2. Select ECG Setup > Beat Volume, then select the appropriate setting for the beat volume:
five bars represent the maximum volume and one bar represents the minimum volume. If
none of bars are selected, the beat volume will be off. Beat frequency has positive
correlation with measurement value.
3.6 Checking Your Monitor Version
To check the monitor version, please select Menu > Common Function > About to check the
monitor software revision.
3.7 Networked Monitoring
Your monitor can be connected to the wired network and the wireless network. If the monitor is
networked, a network symbol is displayed on the screen.
NOTE:
1 Be aware that some network-based functions may be limited for monitors on wireless
networks in comparison to those on wired networks.
2 When selecting dynamic IP mode, please check the IP address from MFM-CMS.
3.8 Setting Languages
To change the language, please:
1. Select Menu > Maintenance > User Maintain, then type the correct password ABC into the
displayed interface.
2. Select the Language option on the popup interface to open the language list.
3. Select the desired language from the list. To make the change validate, please restart the
monitor.
3.9 Calibrating Screens
To calibrate the screen, please refer to the following steps:
1. Select Menu > Maintenance > User Maintain, input the user password ABC, and select
TouchScr Calibration on the User Maintain menu. User can also enter into calibration
interface through pressing shortcut key F9 in connected keyboard.
2. The symbol appears on the screen.
3. Click on the central point of the symbol .
