Patient Monitor User Manual Alarm Information
- 49 -
PR alarm limits are listed as follows: unit (bpm)
Adjustable Range
PR (SpO
2
)
30~300
PR (NIBP)
40~240
PR (IBP)
30~300
NIBP alarm limits are listed as follows: unit (mmHg, kPa, cmH
2
O, 1 mmHg = 0.133 kPa, 1
cmH
2
O=1.36 mmHg)
Patient Type
Adjustable Range (mmHg)
ADU
SYS
DIA
MAP
25~290
10~250
15~260
PED
SYS
DIA
MAP
25~240
10~200
15~215
NEO
SYS
DIA
MAP
25~140
10~115
15~125
TEMP alarm limits are listed as follows:
Adjustable Range
T1
0 C (32 F)~50 C (122 F)
T2
0 C (32 F)~50 C (122 F)
TD
High limit: 0.1 C (32.18 F)~50 C (122 F)
IBP alarm limits are listed as follows: unit (mmHg)
Adjustable Range
Art
0~300
RAP, LAP, CVP, ICP
-10~40
PA
-6~120
P1, P2
-50~300
CO
2
alarm limits are listed as follows:
Adjustable Range
EtCO
2
0 mmHg~150 mmHg
FiCO
2
High limit: 0 mmHg~50 mmHg
AwRR
2 rpm~150 rpm
C.O. alarm limits are listed as follows:
Adjustable Range
TB
23 C (73.4 ºF )~43 C (109.4 ºF )
