C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 103 –
Interface 151
Port 152
General
Configure by Port List Configures connection settings per port 152
Configure by Port Range Configures connection settings for a range of ports 154
Show Information Displays port connection status 155
Mirror 156
Add Sets the source and target ports for mirroring 156
Show Shows the configured mirror sessions 156
Statistics Shows Interface, Etherlike, and RMON port statistics 162
Chart Shows Interface, Etherlike, and RMON port statistics 162
Transceiver Shows identifying information and operational parameters for
optical transceivers which support Digital Diagnostic Monitoring
(DDM), and configures thresholds for alarm and warning
messages for optical transceivers which support DDM
166,
167
Cable Test Performs cable diagnostics for selected port to diagnose any cable
faults (short, open etc.) and report the cable length
170
Trun k
Static 173
Configure Trunk 173
Add Creates a trunk, along with the first port member 173
Show Shows the configured trunk identifiers 173
Add Member Specifies ports to group into static trunks 173
Show Member Shows the port members for the selected trunk 173
Configure General 173
Configure Configures trunk connection settings 173
Show Information Displays trunk connection settings 173
Dynamic 175
Configure Aggregator Configures administration key and timeout for LACP groups 175
Configure Aggregation Port 173
Configure 173
General Allows ports to dynamically join trunks 175
Actor Configures parameters for link aggregation group members on the
local side
175
Partner Configures parameters for link aggregation group members on the
remote side
175
Show Information 181
Counters Displays statistics for LACP protocol messages 181
Internal Displays configuration settings and operational state for the local
side of a link aggregation
182
Table 6: Switch Main Menu (Continued)
Menu Description Page
