HAPTER

| Multicast Filtering Commands

MVR for IPv6

– 1283 –

EXAMPLE

The following shows information about the number of multicast forwarding

entries currently active in domain 1:

Console#show mvr6 domain 1 members

MVR6 Domain : 1

MVR6 Forwarding Entry Count :1

Flag: S - Source port, R - Receiver port.

H - Host counts (number of hosts join the group on this port).

P - Port counts (number of forwarding ports).

Up time: Group elapsed time (d:h:m:s).

Expire : Group remaining time (m:s).

Group Address VLAN Port Up time Expire Count

------------------------------ ---- ----------- ----------- ------ --------

ff05::101 2 00:00:00:19 2(P)

2 Eth1/ 2(S)

1 Eth1/ 4(R) 0(H)

Console#

The following example shows detailed information about a specific

multicast address:

Console#show mvr6 domain 1 members ff00::1

MVR6 Domain : 1

MVR6 Forwarding Entry Count :1

Flag: S - Source port, R - Receiver port.

H - Host counts (number of hosts join the group on this port).

P - Port counts (number of forwarding ports).

Up time: Group elapsed time (d:h:m:s).

Expire : Group remaining time (m:s).

Group Address VLAN Port Up time Expire Count

------------------------------ ---- ----------- ----------- ------ --------

ff05::101 2 00:00:03:18 2(P)

2 Eth1/ 2(S)

1 Eth1/ 4(R) 0(H)

Console#

Table 172: show mvr6 members - display description

Field Description

Group Address Multicast group address.

VLAN VLAN to which this address is forwarded.

Port Port to which this address is forwarded.

Up time Time that this multicast group has been known.

Expire The time until this entry expires.

Count The number of times this address has been learned by MVR (MLD

snooping).
