C
HAPTER
38
| Multicast Filtering Commands
MVR for IPv4
– 1259 –
DEFAULT SETTING
Displays configuration settings for all MVR domains.
COMMAND MODE
Privileged Exec
EXAMPLE
The following shows the MVR settings:
Console#show mvr
MVR 802.1p Forwarding Priority : Disabled
MVR Proxy Switching : Enabled
MVR Robustness Value : 1
MVR Proxy Query Interval : 125(sec.)
MVR Source Port Mode : Always Forward
MVR Domain : 1
MVR Config Status : Enabled
MVR Running Status : Active
MVR Multicast VLAN : 1
MVR Current Learned Groups : 10
MVR Upstream Source IP : 192.168.0.3
.
.
.
Table 161: show mvr - display description
Field Description
MVR 802.1p Forwarding
Priority
Priority assigned to multicast traffic forwarded into the MVR VLAN
MVR Proxy Switching Shows if MVR proxy switching is enabled
MVR Robustness Value Shows the number of reports or query messages sent when proxy
switching is enabled
MVR Proxy Query Interval The interval at which the receiver port sends out general queries
MVR Source Port Mode Shows if the switch only forwards multicast streams which the
source port has dynamcially joined or always forwards multicast
streams
MVR Domain An independent multicast domain.
MVR Config Status Shows if MVR is globally enabled on the switch.
MVR Running Status Indicates whether or not all necessary conditions in the MVR
environment are satisfied. (Running status is true as long as MVR
Status is enabled, and the specified MVR VLAN exists.)
MVR Multicast VLAN Shows the VLAN used to transport all MVR multicast traffic.
MVR Current Learned
Groups
The current number of MVR group addresses
MVR Upstream Source IP The source IP address assigned to all upstream control packets.
