C
HAPTER
5
| Interface Configuration
Traffic Segmentation
– 189 –
TRAFFIC SEGMENTATION
If tighter security is required for passing traffic from different clients
through downlink ports on the local network and over uplink ports to the
service provider, port-based traffic segmentation can be used to isolate
traffic for individual clients.
Traffic belonging to each client is isolated to the allocated downlink ports.
But the switch can be configured to either isolate traffic passing across a
client’s allocated uplink ports from the uplink ports assigned to other
clients, or to forward traffic through the uplink ports used by other clients,
allowing different clients to share access to their uplink ports where
security is less likely to be compromised.
ENABLING TRAFFIC
SEGMENTATION
Use the Interface > Traffic Segmentation (Configure Global) page to enable
traffic segmentation.
CLI REFERENCES
â—† "Port-based Traffic Segmentation" on page 938
PARAMETERS
These parameters are displayed:
◆ Status –
Enables port-based traffic segmentation. (Default: Disabled)
◆ Uplink-to-Uplink Mode – Specifies whether or not traffic can be
forwarded between uplink ports assigned to different client sessions.
â–
Blocking – Blocks traffic between uplink ports assigned to different
sessions.
â–
Forwarding – Forwards traffic between uplink ports assigned to
different sessions.
WEB INTERFACE
To enable traffic segmentation:
1. Click Interface, Traffic Segmentation.
2. Select Configure Global from the Step list.
3. Mark the Status check box, and set the required uplink-to-uplink mode.
4. Click Apply.
