C
HAPTER
4
| Basic Management Tasks
Managing System Files
– 125 –
PARAMETERS
The following parameters are displayed:
◆ Copy Type – The firmware copy operation includes these options:
■
FTP Upload – Copies a file from an FTP server to the switch.
■
FTP Download – Copies a file from the switch to an FTP server.
■
HTTP Upload – Copies a file from a management station to the
switch.
■
HTTP Download – Copies a file from the switch to a management
station
■
TFTP Upload – Copies a file from a TFTP server to the switch.
■
TFTP Download – Copies a file from the switch to a TFTP server.
◆ FTP/TFTP Server IP Address – The IP address of an FTP/TFTP server.
◆ User Name – The user name for FTP server access.
◆ Password – The password for FTP server access.
◆ File Type – Specify Operation Code to copy firmware.
◆ File Name –
The file name should not contain slashes (\ or /),
and the
maximum length for file names is 32 characters for files on the switch
or 127 characters for files on the server. (Valid characters: A-Z, a-z,
0-9, “.”, “-”, “_”)
N
OTE
:
Up to two copies of the system software (i.e., the runtime firmware)
can be stored in the file directory on the switch.
N
OTE
:
The maximum number of user-defined configuration files is limited
only by available flash memory space.
N
OTE
:
The file
“
Factory_Default_Config.cfg
”
can be copied to a file server
or management station, but cannot be used as the destination file name on
the switch.
WEB INTERFACE
To copy firmware files:
1. Click System, then File.
2. Select Copy from the Action list.
3. Select FTP Upload, HTTP Upload, or TFTP Upload as the file transfer
method.
4. If FTP or TFTP Upload is used, enter the IP address of the file server.
5. If FTP Upload is used, enter the user name and password for your
account on the FTP server.
