C
HAPTER
13
| Security Measures
Access Control Lists
– 370 –
SHOWING
ACL HARDWARE
COUNTERS
Use the Security > ACL > Configure Interface (Show Hardware Counters)
page to show statistics for ACL hardware counters.
CLI REFERENCES
â—† "show access-list" on page 966
â—† "clear access-list hardware counters" on page 965
PARAMETERS
These parameters are displayed:
◆ Port – Port identifier. (Range: 1-28/52)
◆ Type – Selects the type of ACL.
◆ Direction – Displays statistics for ingress.
◆ ACL Name – The ACL bound this port.
◆ Action – Shows if action is to permit or deny specified packets.
◆ Rules – Shows the rules for the ACL bound to this port.
◆ Time-Range – Name of a time range.
◆ Hits – Shows the number of packets matching this ACL.
6
◆ Clear Counter – Clears the hit counter for the specified ACL.
WEB INTERFACE
To show statistics for ACL hardware counters:
1. Click Security, ACL.
2. Select Configure Interface from the Step list.
3. Select Show Hardware Counters from the Action list.
4. Select a port.
5. Select ingress or egress traffic.
6. Due to a hardware limitation, statistics are only displayed for permit rules.
