C
HAPTER
14
| Basic Administration Protocols
Remote Monitoring
– 478 –
PARAMETERS
These parameters are displayed:
◆ Port – The port number on the switch.
â—† Index - Index to this entry. (Range: 1-65535)
â—† Interval - The polling interval. (Range: 1-3600 seconds; Default: 1800
seconds)
â—† Buckets - The number of buckets requested for this entry.
(Range: 1-65536; Default: 50)
The number of buckets granted are displayed on the Show page.
â—† Owner - Name of the person who created this entry. (Range: 1-127
characters)
WEB INTERFACE
To periodically sample statistics on a port:
1. Click Administration, RMON.
2. Select Configure Interface from the Step list.
3. Select Add from the Action list.
4. Click History.
5. Select a port from the list as the data source.
6. Enter an index number, the sampling interval, the number of buckets to
use, and the name of the owner for this entry.
7. Click Apply
Figure 271: Configuring an RMON History Sample
