Edwards STP-iS1607 Series User Manual

STP-iS1607 Series Turbomolecular Pump
MT-94E-001-C
Page 117
5
SERIAL COMMUNICA
TION PROTOCOL
Example:
1. Input operation port: 01
hex
= I/O REMOTE
2. TMS Option: FF
hex
= DISABLE
4. Second Damage Limit Option: 00
hex
= ENABLE
5. First Damage Limit Warning: 00
hex
= ENABLE
6. Pump Runtime Over Warning: FF
hex
= DISABLE
7. Pump Runtime Over Warning hours: 000003E8
hex
= 1,000 (×100 hours)
8. Imbalance Warning: 00
hex
= ENABLE
9. Pump Overload Warning: FF
hex
= DISABLE
10. Pump Overload Warning Motor current: 03E8
hex
= 1,000 (×0.1%)
11. Pump Overload Warning Rotational speed: 0000
hex
= 0 (×0.1%)
12. Serial communication time out: 003C
hex
= 60 sec.
Parameter
1
2
3
4
5
ASCII
0
1
F
F
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
0
0
0
0
HEX
30
31
46
46
30
30
30
30
Parameter
6
7
8
ASCII
F
F
0
0
0
0
0
3
E
8
0
0
HEX
46
46
30
30
30
30
30
33
45
38
30
30
Parameter
9
10
11
12
13
ASCII
F
F
0
3
E
8
0
0
0
0
0
0
3
C
*1
*1
*1
*1
*1
*1
HEX
46
46
30
33
45
38
30
30
30
30
30
30
33
43
Parameter
13
ASCII
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
HEX
*1
System reservation.
