Ellisys Vanguard User Manual

Bluetooth Analyzers
Page 116 of 264 | Overviews
2. Select Reset Time Reference.
The events captured are reset with the timestamp values originally when the capture was taken.
8.5 Synchronization to Other Panes
By default, the Overviews are automatically synchronized to other panes to give the user a comprehensive
understanding of traffic captured, and to ease navigation. Navigation through an Overview will cause
synchronized tracking in the
Instant Timing pane, the Details pane, the Instant Channels pane, the Instant
Spectrum
view, Instant Channels pane, Instant Throughout pane, Instant Audio pane, and the Raw Data
pane.
Conversely, selection of timestamps located in the
Security pane and Instant Piconet pane allow the user to
jump to relevant locations in the Overviews.
A double click on the graphical audio representations in the
Instant Audio pane will force the pertinent Overview
to navigate to the location where the double click is made.
If the
Instant Timing pane is configured to disable synchronization with the Overview(s), i.e., to not track
selections made in the Overview(s), the user can force the
Instant Timing pane to jump to the selected
Overview event as described below.
To force the selected event in an Overview to display in the Instant Timing pane:
1. Right-click in the desired Overview.
2. Select Show in Instant Timing view.
The
Instant Timing pane jumps to the event selected in the Overview.
