Bluetooth Analyzers
Page 216 of 264 | Instant Throughput
The analyzer application retains new timing origin entries. Click the Down arrow
in the origin field to view and select previously entered timing origin entries.
14.2 Zooming In and Out
The
Instant Throughput
view provides a zoom feature to expand or contract the display to view information
from a high level or low level.
To use the mouse to zoom:
1. Place the pointer over the
Zoom
bar, located at the bottom of the display (recommended or
alternatively, click on Zoom .
The pointer changes to a spyglass .
2. Press and hold the left mouse button and drag the pointer to the right to zoom in and expand the
display or drag to the left to zoom out and contract the display.
The mouse cursor automatically rolls around the screen, such that the user can
smoothly scroll substantial amounts of time without having to press and release
the mouse button several times.
The mouse wheel can be used to zoom in and zoom out by moving the wheel
forward to zoom in and backwards to zoom out. The zoom is centered at the
mouse position.
To use the keyboard to zoom:
1. Press the UP-Arrow key to zoom in, and the DOWN Arrow key to zoom out.
To use the Navigator bar to zoom:
1. Position the mouse over the left or right edge of
Navigator w
indow:
2. Press and hold the left mouse button and drag left or right as desired to zoom in or out.
