Analyzer User Manual
Instant Throughput | Page 217 of 264
To define a new time span:
1. Type the new timing span in the
span
field.
The following values are allowed:
s – seconds
ms – milliseconds
ns – nanoseconds
ps – picoseconds
If a unit is not specified, then the previously displayed unit is used.
2. Press ENTER.
The
Instant Throughput
display is updated with the new span value.
The analyzer application retains new time span entries. Click the Down
in the span field to view and select previously entered time span entries.
14.3 Making Time Measurements
The
Instant Throughput
view provides quick and simple methods to manually characterize timing between
throughput events. Timing cursors can be duplicated or frozen with a right-click, to enable the addition of more
cursors.
Timing cursors available include:
Timing Cursors
A-B Independent Cursors
To make a timing measurement:
1. Select the pointer icon at the top left of the
Instant Throughput
view.
2. Left click in the desired location or on the desired event.
