Bluetooth Analyzers
Page 88 of 264 | Capturing Traffic
The position of the wireless device under test relative to the analyzer is
important to consider. On the analyzer application’s Welcome screen, (View
menu > Other Windows > Welcome) please see the Expert Note entitled
EEN_BT04 – Optimal Placement of Your Analyzer
for information on how to
position the analyzer relative to your devices for optimal captures. For
Vanguard, please review
Section 7.3, Bluetooth Capture Diversity
.
2. Click OK.
7.6 Selecting an Analyzer
It is possible that multiple analyzers may be attached to a single PC hosting the analyzer desired for recording.
To select an analyzer:
1. Select Record | Select an analyzer from the menu. Alternatively, select the drop-down arrow
located on the Record button located on the toolbar.
The
Available analyzers
dialog appears (shown: Explorer connected over USB and Vanguard connected over
Ethernet):
2. Select the desired analyzer.
