Bluetooth Analyzers
Page 196 of 264 | Instant Audio
12. Instant Audio
The
Instant Audio
feature provides a visual representation of captured audio traffic that can be played real-
time (during recording) or post-capture, looped, or configured to play selected user-defined ranges. As audio is
played, a vertical cursor tracks the present position of the audio being played. Various control features are
provided, including rewind, looping, pausing, enable and disable of selected streams, and other controls. Any
available sound devices installed on the controlling PC can be selected for use by this feature.
For LE Audio, two proprietary features are included. These include Auto-Detect for the LC3 codec (detects and
decodes LC3 traffic, even without capture of configuration parameters), and t
ZERO Tracking Technology
(Vanguard model only, delivers high-fidelity capture of isochronous traffic from the initial instance of isochronous
traffic).
To better ensure optimal reception by the analyzer of audio traffic, please
review Expert Note
EEN_BT04, Optimal Placement of Your Analyzer
, located
in the Welcome view of the application.
To export audio to WAV format, see Export of Bluetooth Audio in Section 4.9.
To access the Instant Audio pane:
1. Select View | Instant Audio from the menu The
Instant Audio
pane appears:
User Controls and Toolbar
The
Instant Audio
pane provides various user controls. The table below lists the Instant
Audio
toolbar buttons
and their actions:
Pointer Mode.
