Bluetooth Analyzers
Page 94 of 264 | Capturing Traffic
2. Select the Advanced tab.
3. Click on Custom and browse to the desired directory.
4. Click OK.
Check the Ask for recovery… check box to program the application to prompt
the user to recover temporary files after a crash. This box is enabled by default.
7.13 Conducted Recordings
In some cases, users may require a cabled connection between the analyzer’s SMA connector and
the system under test, in lieu of antenna reception. This is referred to as conducted recording.
This setup is particularly useful to avoid interferences (and thereby decrease the packet error
rate).
Some care must be taken with such a setup to not saturate the receivers of the devices under
test and the analyzer. When the analyzer’s receiver is getting too much power, the reception
quality will drop, and the capture file may be unusable. In that case, the RSSI field for the
packets (shown in the Details pane) will be indicated as Too High (shown below).
