Ellisys Vanguard User Manual

Bluetooth Analyzers
Page 260 of 264 | Vanguard Technical Characteristics
30. Vanguard Technical Characteristics
Bluetooth Capture Characteristics
 Ellisys Rainbow™: Industry's first
wideband concurrent capture of all
Bluetooth channels. Introduced in 2010.
 Frequency band: 2.402-2.480 GHz
 Sensitivity range: From -90 to +15 dBm
 Gain: Programmable from -30 to +30 dB
 Modulations: All BR/EDR/LE modulations
(GFSK 1/2Mbps, p/4-DQPSK, 8-DPSK)
 Baseband: Support of Bluetooth 5,
upgradeable by software. Preliminary
support of non-released specifications
available.
Wi-Fi Capture Characteristics
 IEEE 802.11 a/b/g/n/ac (3 streams)
 Channel width 2.4GHz: 20MHz, 40MHz
 Channel width 5GHz: 20MHz, 40MHz,
80MHz
 11n MCS: 0 to 23 (up to 3 streams)
 11ac MCS: 0 to 9 (up to 3 streams)
 Guard Interval: 800ns (long) and 400ns
(short)
 Frame encoding: BCC, LDPC, STBC,
Greenfield
 Max AMPDU size: 65,535 bytes
 Timing accuracy: 125 ns
WPAN Capture Characteristics
 IEEE 802.15.4-2011
 Channels: All 16 2.4 GHz channels (11 to
26)
 Data rate: 250 kbps
 Modulation: O-QPSK
 Timing accuracy: 125 ns
Logic Capture Characteristics
 Maximum bandwidth: 20 MHz
 Sampling precision: 5 ns
 Supported input voltage: 1.8 to 3.3V
HCI Capture Characteristics
 USB transport: Low, Full, and High Speed,
with automatic detection
 UART transport: Up to 8 Mbit/s,
automatic detection of all parameters
 SPI transport: Up to 8 Mbit/s, automatic
detection of all parameters
Low-speed Serial Capture Characteristics
 UART: Up to 8 Mbit/s automatic
detection of all parameters
 SPI: Up to 8 Mbit/s, automatic detection
of all parameters
 I2C: Up to 1 Mb/s
 SWD: Up to 8 Mb/s
Timing
 Clock: ±10ppm frequency accuracy over -
10 to +60 degrees Celsius range
 BR/EDR/LE timestamp accuracy: ±125ns
 Wi-Fi timestamp accuracy: ±125ns
 WPAN timestamp accuracy: ±125ns
 USB HCI timestamp accuracy: ±16.7ns
 Logic timestamp accuracy: ±5ns
Embedded Memory
 512 MB of FIFO memory
 Data is stored in highly optimized format
 Analyzed data is uploaded in real time
