Analyzer User Manual
Display Filters | Page 141 of 264
4. Select the Packets icon.
The Overview updates to show only individual packets.
9.5 Instant Piconet Keep-Only and Keep Involving Filters
The
Instant Piconet
pane provides filtering that enables the user to show/hide selected piconets, scatternets,
paging events, and inquiry events. This filter will update all displays and panes. For more information on the
Instant Piconet
pane, see
Section 16, Instant Piconet Pane
.
To set an Instant Piconet Keep Only or Keep Involving Filter:
1. Position the mouse pointer over the desired piconet or scatternet and right-click.
Navigate to a piconet event (so that it will be displayed in the
pane) by selecting an associated event in the Overview (or other panes) or by
using the navigation buttons located at the bottom-left of the
pane.
A Keep Only / Keep Involving filter dialog appears as shown below:
2. Select the desired option to keep the selected piconet or scatternet.
All displays and panes are updated to remove all but the selected piconet or scatternet traffic. The Filtering
button (on the Main Tool Bar) updates to show the selected filter:
