Analyzer User Manual
User Interface Reference | Page 39 of 264
4.2 Main Toolbar
The table below shows the Analyzer toolbar buttons and their actions:
Creates a new empty capture file.
Opens a previously saved capture file.
Saves a capture file.
Saves a filtered capture file (devices that are filtered-in).
Opens the Search dialog.
Starts a recording on the selected analyzer.
Stops the current recording.
Aborts current recording and restarts a new one.
Continue Saves the current capture and starts the next.
Sets the line selected in an Overview at 0.000 000 000 or to
a value selectable by the user.
Resets the time reference to its original value.
Navigate to the previous selection history.
Opens the Markers menu.
Jumps to previous marker.
Jumps to next marker.
Opens the Device Traffic Filters menu.
Guide
Opens the User Guide.
