Analyzer User Manual
Instant Throughput | Page 215 of 264
The mouse cursor automatically rolls around the screen, such that the user can
smoothly scroll substantial amounts of time without having to press and release
the mouse button several times.
To use the keyboard to pan:
1. Press LEFT or RIGHT Arrow to move incrementally left or right.
To use the Navigator bar to pan:
1. Position the mouse over the middle of the
Navigator
window.
2. Press and hold the left mouse button and drag left or right as desired to pan left or right.
To jump to another location:
1. Press keyboard HOME to jump to the start of the capture, or END to jump to the end of the capture.
2. Alternatively, use the
Navigator
bar to jump to a selected location by double-clicking at the desired
location in the
Navigator
bar.
To define a new timing view origin:
1. Enter a timestamp value in the
origin
box.
The following values are allowed:
s – seconds
ms – milliseconds
ns – nanoseconds
ps – picoseconds
2. Press ENTER.
If a unit is not specified, then the previously displayed unit is used.
The
Instant Throughput
view is updated with the new origin.
