Ellisys Vanguard User Manual

Analyzer User Manual
Explorer Technical Characteristics | Page 257 of 264
Front-Panel Indicators
 Power: unit powered on
 Operating: unit performing
requested task
 Trigger: trigger event detected (not
implemented)
 Capture: BR/EDR and/or LE packet
captured
 HCI: HCI packet captured
Rear-Panel Connectors
 Computer: USB 2.0 Standard-B
 Power: 12-24 VDC, max 18 W
 Trigger: SMA in and out, 50 Ω, max
5VDC (Not Implemented)
 IO Probe: supports UART / SPI HCI,
WCI-2 and logic analysis
 Inter-equipment: in and out,
supports connection of several units
Enclosure
 174 x 111 x 58 mm (6.9 x 4.4 x 2.3'')
 1.0 kg (2.0 lbs.)
Hardware Upgrade
 The Ellisys Rainbow™ engine is
automatically updated with each
software release (no user intervention
required)
Maintenance and Licensing
 Free lifetime software updates – no
maintenance fees
 Free full-featured viewer software –
easily share annotated traces between
computers and colleagues and replay
captured traffic
 Use Ellisys hardware on any computer –
no additional licenses needed
Warranty
 Two-year limited warranty [STD and PRO]
 Three-year limited warranty [ENT]
