Bluetooth Analyzers
Page 26 of 264 | Analyzer Hardware Overviews
Power LED
The Power LED indicates if the unit is correctly powered from the from any of the power sources (PoE, USB
Power Delivery, or DC Power). It also indicates whether an IP address has been acquired or is being acquired.
First-stage bootloader loading.
Operating System loading.
Power issue.
USB control port-connected but not DC-
powered (assumes USB control port is
not providing
enough power/not USB Power Delivery compatible).
t blue: Unit powered, and operating system booted.
Backup battery enabled.
Operating on battery after a DC-power loss.
Not powered or powered off.
