Bluetooth Analyzers
Page 30 of 264 | Analyzer Hardware Overviews
Clock IN
SMA connector used for sending TTL voltage level shift or pulse to external equipment. Reserved future use.
Clock OUT
SMA connector used for accepting TTL voltage level shift or pulse from external equipment. Reserved future
use.
Ethernet
Control port receptacle. 100Mbps minimum (1 Gigabit Ethernet supported). Used for power (PoE, if available)
and control of the Vanguard.
Ground Jack
Connected to Vanguard chassis.
