Instant Piconet Pane
– Displays a graphical representation of devices, piconets, and scatternets, along
with connection and topology characteristics, throughput, and RSSI indications.
Instant Filter Bar
– Text query approach that uses programmatic entries to precisely filter the contents
of the active Overview.
Instant Channels Pane
– Displays various per-channel transmission statistics.
Instant Throughput Pane
– Displays various data throughput characteristics.
Security Pane
– Displays security information and allows for user input of Link Keys, PIN, etc.
Mesh Security Pane
– Displays keys relating to Mesh protocol and allows for various user inputs.
Message Log
– Provides a way for users to enter text data to be displayed in time with traffic captured. Can also
be used by the Injection API to programmatically inject information from other sources (see
Section 7.7, Ellisys
Injection API
).
