EMC-PARTNER TRA3000 S - Page 84

TRANSIENT3000
84/162
Example Voltage
The voltage will be increased from 2000 V to 8000 V with a 500 V step voltage after every 10 discharges.
loaded test EUT power v, i
possible ramps at EFT
6.2.3.2.2 Definition ramp ESD
number of pulses
Nominal
= 8000V
t
V
Start 2000V
e.g. 10 pulses per step
