EMC-PARTNER TRA3000 S - Page 85

TRANSIENT3000
85/162
6.2.3.3 SURGE Ramp
loaded test EUT power v, i
possible ramps at
SURGE
6.2.3.3.1 Definition SURGE ramp
Example Voltage
loaded test EUT power v, i
V-Peak ramps at
SURGE
The nominal voltage can also be selected in „Main“
menu.
6.2.3.3.2 Definition SURGE ramp
number of pulses
number of pulses
Start
Nominal V, °
Nominal
= 1000V
t
V,°
V
Start 500V
e.g. 5 pulses per step
