104
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 11: SERIAL LINK - DRIVE CHARACTERISTICS - MISCELLANEOUS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
: Drive variant
Adjustment range :0 to 99
Indication of the drive type.
0 (Display) (N): Drive with display only. Parameters can be
set only via the LCD keypad or a PC.
1 (Local control) (CP): Drive fitted with local controls (1 FWD
key ( ), 1 REV key ( ), 1 Stop key ( ) and 1
potentiometer). The parameters are set as described above.
2 (6 keys) (SEt): Drive fitted with 6 keys (1 FWD key ( ), 1
REV key ( ), 1 Stop key ( ) one ( ) key, 1 ( ) key and
one Mode key ( )). The user menu parameters can be set
using the , and keys. Advanced parameters can be
accessed via the LCD keypad or PC.
3 to 99: Reserved.
WARNING:
After modifying this parameter, return to factory settings
(see 11.43).
: Drive identification code
Adjustment range :0 to 32000
This product code gives information on the drive rating, size,
hardware version and variant.
When the nameplate is not visible, this code can be given to
your CONTROL TECHNIQUES contact.
: Advanced menu access code
Adjustment range :0 to 9999
Factory setting :149
This parameter is used to limit access to menus 1 to 21 when
setting the parameters via the LCD keypad.
If this parameter does not equal 0, the value of parameter
11.61 should be entered to enable switching from Menu 0 to
Menu 1.
In factory settings mode, simply enter the value 149 to access
all menus.
: Not used
: Timeout on RJ45
Adjustment range :0 to 25.0 s
Factory setting :0
Used to generate the "SCL" trip if no communication has
taken place within the time period set by this parameter.
The value 0 deactivates monitoring of the communication on
the drive's RJ45 connector.
: Save parameters in EEPROM
Adjustment range :0 or 1
Factory setting :0
0 (No) (OFF)
1 (Yes) (On)
This parameter is used to store in EEPROM the values of
drive parameters that have been changed via the fieldbus.
- Select the menu(s) to be saved using 11.65
(set 11.65 = 0 to save all the menus).
- Confirm the save using 11.64 = 1 (On).
- Saving completed is indicated by 11.64 reverting to 0
(OFF).
: Menus of parameters to be saved in
EEPROM
Adjustment range :0 to 21
Factory setting :0
This parameter is used to select the menu(s) to be saved. Set
11.65 = 0 to save all the menus (see 11.64).
11.59
M
M
11.60
11.61
11.62
11.63
11.64
11.65
