20 - MENU 21: OPERATING PARAMETERS FOR A SECOND MOTOR
20.1 - List of parameters in Menu 21
: Function not available.
Parameter Name Type Adjustment range Factory setting
User
setting
21.01 Motor 2 maximum reference clamp R-W
0 to 32000 rpm
Eur: 1500 rpm
USA: 1800 rpm
21.02 Motor 2 minimum reference clamp R-W/P
0 to 32000 rpm
0
21.03 Motor 2 reference selector R-W 0 to 4 0
21.04 Motor 2 acceleration rate R-W
0 to 600.0 s/1000 rpm 3.0 s/1000 rpm
21.05 Motor 2 deceleration rate R-W
0 to 600.0 s/1000 rpm 5.0 s/1000 rpm
21.06 Motor 2 rated frequency R-W 0 to 400.0 Hz
Eur: 50.0 Hz
USA: 60.0 Hz
21.07 Motor 2 rated current R-W
0 to drive rated current
(A)
Motor rated
current (A)
corresponding to
the drive rating
21.08 Motor 2 rated speed R-W
0 to 9999 rpm
Motor rated speed
(rpm)
corresponding to
the drive rating
21.09 Motor 2 rated voltage R-W 0 to 480 V
Eur L: 200 V
USA L: 230 V
Eur H: 400 V
USA H: 460 V
21.10 Motor 2 rated power factor (cos ϕ) R-W 0 to 1.00 0.85
21.11 Motor 2 number of poles R-W 0 to 4 0
21.12 Motor 2 stator resistance R-W 0 to 32.000 Ω 0
21.13 Motor 2 voltage offset RO 0 to 25.5 V -
21.14 Motor 2 inductance R-W 0 to 3200.0 mH 0
21.15 Motor 2 parameters active RO/P 0 or 1 -
21.16
Not used
to
21.23
21.24 Motor 2 stator inductance L
S
R-W 0 to 3200.0 mH 150.0 mH
21.25
Not used
to
21.29
21.30 Motor volts per 1000 rpm (Ke) R-W 0 to 10000 V 98 V
21.31
Not used
to
21.50
21.51 q axis inductance R-W 0 to 999.9 mH 150.0 mH
