11 - MENU 9: LOGIC FUNCTIONS, MOTORISED POT AND BINARY SUM
11.1 - List of parameters in Menu 9
Parameter Name Type Adjustment range Factory setting
User
setting
9.01 - 9.02
Logic functions 1 to 4 output RO 0 or 1 - -
9.61 - 9.71
9.03 Motorised pot output RO ± 100.0% - -
9.04 - 9.14
Logic functions 1 to 4 source 1 R-W/P 0.00 to 21.51 0.00
9.64 - 9.74
9.05 - 9.15
Logic functions 1 to 4 source 1 invert R-W 0 or 1 0
9.65 - 9.75
9.06 - 9.16
Logic functions 1 to 4 source 2 R-W/P 0.00 to 21.51 0.00
9.66 - 9.76
9.07 - 9.17
Logic functions 1 to 4 source 2 invert R-W 0 or 1 0
9.67 - 9.77
9.08 - 9.18
Logic functions 1 to 4 output invert R-W 0 or 1 0
9.68 - 9.78
9.09 - 9.19 Not used
9.10 - 9.20
Logic functions 1 to 4 destination R-W/P 0.00 to 21.51
0.00
9.60 - 9.70
9.11 to 9.13
Not used
9.21 Motorised pot mode R-W 0 to 3 2
9.22 Motorised pot bipolar select R-W 0 or 1 0
9.23 Motorised pot rate R-W 0 to 250 s 20 s
9.24 Motorised pot scale factor 0 to 2.50 1.00
9.25 Motorised pot destination R-W/P 0.00 to 21.51 0.00
9.26 Motorised pot up R-A 0 or 1 -
9.27 Motorised pot down R-A 0 or 1 -
9.28 Motorised pot reset R-W 0 or 1 0
9.29 Binary sum ones input R-A 0 or 1 - -
9.30 Binary sum twos input R-A 0 or 1 - -
9.31 Binary sum fours input R-A 0 or 1 - -
9.32 Binary sum output RO 0 to 39 - -
9.33 Binary sum destination R-W/P 0.00 to 21.51 0.00
9.34 Binary sum offset R-W 0 to 32 0
9.35
to 9.69
Not used
9.62
and 9.63
Not used
9.72
and 9.73
Not used
